Pit Bull's F0082A-000 Fully Adjustable Rear Spooled Motorcycle Stand.
Fully Adjustable Rear Stand - height adjustable 11.75" - 14.75", width adjustable 9.625" - 15.25" with support plates to fit spooled motorcycles.
This stand was designed for use with late model bikes that have low hanging stock rear fenders and have not had a fender eliminator kit installed(like the 2nd gen Hayabusa, ZX14, ZX14R, Ninja 1000). This stand is also ideal for Kawasaki ZRX motorcycles to give better leverage when lifting than you would get with a traditional stand. The '16+ Triumph Thruxton 1200 also benefits from using this stand due to a significant increase in leverage.
This stand has height AND width adjustability and is available exclusively with a removable handle. If you would like to order the support plates to lift non-spooled bikes, you can find those here: PB-F0042-001.
Requires bike specific spools listed below. Please select the correct spool/adapter from the drop down menu above.
APRILIA
RS 250 - F0013-000 6mm
RSV MILLE - F0013-000 6mm
TUONO - F0013-000 6mm
FALCO - F0013-000 w/ Falco spacers
RSV4 - F0013-000 6mm
"Spooled" Aprilia models not listed will use F0013-000 6mm
BMW
S1000RR - F0009E-000 8mm w/ 0.18” spacer
S1000R - F0009E-000 8mm w/ 0.18” spacer
HP4 - F0009E-000 8mm w/ 0.18” spacer
S1000SX - F0009E-000 8mm w/ 0.18” spacer
Any BMW models not listed do not use spools, or have not been checked
HONDA
RS125 '95 & on - F0009-000 8mm
RC51 '00,'02 & on - F0009-000 8mm
RC51 '01 - No spools (use a different stand)
CBR600RR - F0009-000 8mm
CBR954RR - F0009-000 8mm
CBR1000RR - F0009-000 8mm
Any Honda models not listed do not use spools, or have not been checked
INDIAN
FTR 1200 - F0009-000
Any Indian models not listed do not use spools, or have not been checked
KAWASAKI
EX250 (up to '07) - No spools (use a different stand)
Ninja 250/300 ('08+) - F0023-000 10mm
Ninja 400 - F0009E-000 8mm w/ 0.18” spacer
ZX6R ('95 - '97) - F0011-000 12mm w/ two short adapters
ZX6R/ZX6RR('98 - '12) - F0023-000 10mm
ZX6R ('13 - '20) - F0009-000 8mm
ZZR600 - F0023-000 10mm
Ninja 650R (up to ’16) - F0023-000 10mm
Ninja 650R / Z650 (’17+) - F0009-000 8mm
Versys 650(up to '12) - F0023-000 10mm
Versys 650('13+) - F0009-000 8mm
Vulcan S 650 - F0023-000 10mm
ZX7R (All) - F0010-000 12mm w/ short/long adapters
ZX9R (up to '97) - F0010-000 12mm w/ short/long adapters
ZX9R('98+) - F0023-000 10mm
Z800 - F0009E-000** 8mm w/ 0.18” spacer - **Remove before riding
Z900 - F0009E-000 8mm w/ 0.18” spacer
Z900RS - F0009C-000** 8mm w/ 0.6” spacer - **Remove before riding
ZX10R (up to '10) - F0023-000 10mm
ZX10R ('11-'20) - F0009-000 8mm
ZRX1100/ZRX1200 - F0023-000 10mm
ZX12/ZX14 - F0023-000 10mm
Ninja 1000/Z1000 (up to '13) - F0023-000* 10mm *do not use delrin
Ninja 1000/Z1000 ('14+) - F0009-000* 8mm *do not use delrin
KTM
RC390/Duke390 (early models) - F0023-000 10mm
RC 390/Duke 390 (? – ’20) - F0023A-000 10mm w/ 1.5 thread pitch
Note: KTM 390 models - verify your thread pitch as we are not sure when the change occurred.
690 Superduke - F0023A-000 10mm w/ 1.5 thread pitch
790 Duke - F0023A-000 10mm w/ 1.5 thread pitch
890 Duke - F0023A-000 10mm w/ 1.5 thread pitch
990 Superduke - F0023A-000 10mm w/ 1.5 thread pitch
RC8R - F0009-000 8mm
Note: All KTM's using the F0023A-000 require special bolts and
are only available with Delrin spool kits
SUZUKI
GSX250R - F0009-000 8mm
500 Gamma - F0009-000 8mm
RF600R/RF900R - F0009-000 8mm
GSXR600 - F0009-000 8mm
SV650 - F0009-000 8mm
GSXR750 - F0009-000 8mm
GSXR1000 ('01+) - F0009-000 8mm
SV1000 - F0009-000 8mm
TL1000S/TL1000R - F0009-000 8mm
GSXR1100 - F0009-000 8mm
GSXR1300 Hayabusa - F0009-000 8mm
B King - F0009-000 8mm
Any and all Suzuki bikes that have spooled swingarms, use 8mm (F0009-000) spools.
There are no exceptions as of the date of this update. We will update the fitting chart
if this changes in the future.
TRIUMPH
Daytona 675 (up to '10) - F0013-000 6mm
Daytona 675 ('11-'12) - F0009-000 *** 8mm
Daytona 675 ('13 & up) - F0009C-000 *** 8mm w/ 0.6” spacer
Street Triple 675 (up to '10) - F0013-000 6mm
Street Triple 675 ('11-'12) - F0009-000 8mm
Street Triple 675 ('13 & up) - F0009C-000 8mm w/ 0.6” spacer
Street Triple 765 - F0009C-000 8mm w/ 0.6” spacer
Tiger 800/800XC - F0009C-000 8mm w/ 0.6” spacer
Thruxton 900 - No spools (use a different stand)
Thruxton 1200 - (’16+) F0009-000 8mm
Bobber (’17+) - F0009C-000 8mm w/ 0.6” spacer
Note: *** On '12-‘13 model Triumph 675, verify your spool size as it may be 6mm or 8mm. There
were some inconsistencies based on VIN
Any Triumph models not listed do not use spools, or have not been checked
YAMAHA
TZ250 - F0023-000 10mm
TZR250 - F0023-000 10mm
R3 - F0013-000 6mm
FZR400 ('90 Only) - F0023-000 10mm
FZR400/600/1000 (exc.’90 FZR400) - No spools (use a different stand)
YZF600(all)/SECA II - No spools (use a different stand)
R6 ('99 & up) - F0013-000 6mm
R6S ('06 -'09) - F0013-000 6mm
YZF750/YZF1000 (ex R1) - F0023-000 10mm
FZ-07 or MT-07 - No spools (use a different stand)
FZ8 - F0013-000 6mm
FZ-09 or MT-09 - F0013-000 6mm
FZ1('01 & up) - No spools (use a different stand)
R1 ('98 & up) - F0013-000 6mm
FZ or MT-10 (’16 & up) - F0013-000 6mm
V-MAX (’09 & up) - F0013-000 6mm
Any Yamaha models not listed do not use spools, or have not been checked
